Dual-Station Manual Push-Type Pipe Deburring Machine (100mm Capacity)

The Dual-Station Manual Push-Type Deburring Machine is a high-productivity solution designed for the rapid cleaning of round pipe and tube ends. Featuring two independent working stations, this machine allows two operators to work simultaneously, doubling your output. Each station is equipped with dedicated tools for internal (ID) and external (OD) deburring. With a capacity of up to 100mm, operators simply push the tube manually into the rotating cutters for instant, burr-free results. It is the perfect, low-maintenance workhorse for high-volume fabrication environments.

Product Overview

Maximized throughput meets simple operation with our Dual-Station Manual Push-Type Deburring Machine. Unlike traditional chamfering machines that require clamping and lever-feeding, this machine is designed for “continuous flow” deburring. By utilizing a high-speed rotating tool assembly and a manual-push workflow, it provides the fastest possible way to clean tube ends after cutting.

The Dual-Station Advantage

This machine is engineered to be a central hub for your finishing department. With two independent stations powered by a heavy-duty motor, you can deploy two workers at a single machine. This setup effectively halves your processing time and maximizes floor space efficiency.

Key Specifications & Features:

Dual-Operator Capacity: Two independent working ends allow for simultaneous operation without performance loss.
4-Tool System: Each station features one ID cleaning tool and one OD cleaning tool, ensuring total coverage of the pipe end in a single push.
Manual Push Action: No clamping required. The operator simply guides the round pipe (up to 100mm) into the rotating head for instant deburring.
Safety-First Design: Tooling is housed within protective guards to ensure operator safety while maintaining high visibility of the workpiece.
High-Speed Spindles: Optimized RPM settings provide a smooth, clean finish on steel, stainless steel, aluminum, and copper.
Robust Construction: A heavy, vibration-dampening frame ensures the machine remains stable during continuous, high-volume use.

Operational Workflow:

Select Station: Operators stand at either end of the machine.
Push: The operator holds the tube and pushes the end into the rotating tool head.
Clean: The ID and OD tools simultaneously strip away burrs and sharp edges.
Repeat: The process takes only 1–2 seconds per end, allowing for massive daily production numbers.

Why Choose This Machine?

If your facility processes thousands of tubes per day and you find that clamping-style machines are too slow, this Push-Type Deburring Machine is your solution. It eliminates the “open-clamp-close” cycle time, moving the focus entirely to the cleaning process. It is simple, rugged, and built for the most demanding production schedules.
